The EPDM IS200EPDMG1A from GEs EX2100 series. This module is a power distribution module that is supplied by one/two 115 VAC and 125 VDC. When being powered the VAC and VDC are powered by a DACA module. This module will typically power an EGPA board.

All published products are in stock, and images cannot correspond to each one. We have inventory and can contact professional customer service personnel

Phone ：15685359870

mailbox： 3165088973@qq.com

Product Description

The Exciter Power Distribution Module IS200EPDMG1A is used to distribute power for the input/output terminal, protection, and control boards within the EX2100 series. Typically the module is mounted on the side of the EPBP module.

The power supply that comes through the IS200EPDMG1A must be filtered, and the VAC of 115 on the EPDM needs to filter to a VDC. To do so the IS200EPDMG1A module will be used in conjunction with a DACA module which will take the 115 VAC and filter it to 125 VDC. When the VAC has been converted to a VDC, the two or potentially three VDC will be conjoined to create the DC source supply that will be labeled as P125V and N125V. When the center has been grounded a nominal voltage of -62.5 V and +62.5 V will be apparent.
