GE PC Board DS200CLACG1AAA has a 2-pin connector, four test points, and four screw holes for mounting.The GE PC Board DS200CLACG1AAA also has test points that can be used to test the circuitry on the board.Board dimensions are 2.5 inches high and 5 inches long.The screws are designed to line up with matching holes in the drive plate cage.When you remove the faulty drive, note the location of the board in the rack and retain the four screws and washers you removed from the old board.Use two hands to remove the old board.Hold the screwdriver with one hand and turn it.Use your other hand to hold the screws and washers to prevent them from falling into the drive.If one or more screws and washers fall into the drive, stop the procedure and locate and retrieve these items.Anything left in the drive may pose a safety hazard and may cause electric shock or damage moving parts inside the drive.When you perform replacement work, you must use a wrist strap to prevent static electricity from building up.One end of the strap wraps around your wrist, while the other end is designed with a clip that allows you to secure it to a bare metal surface.This could be a bare metal surface on a workbench leg or support structure.Some wrist straps have a plug that you can connect to a matching connector on your workbench.

DS200TCRAG1AAA is a relay output board developed by GE.The board contains 30 plug-in relays.There are also four 34-pin connectors and four 12-pin connectors.JOS, JOR, JOT, and JO are the IDs assigned to 34-pin connectors.The 12-pin connector IDs are JS4, JS3, JS5, and JS6.When you receive the DS200TCRAG1AAA, it is critical to avoid static electricity buildup when handling and storing the board prior to installation.When the box arrives at your location, inspect it to make sure it has not been damaged by improper handling during shipping.Check if the box is crushed, dented or torn.Open the box and collect all leaflets, loose papers and instructions.Remove the packaging material from the top of the box.While the circuit board is still in the anti-static bag, use two hands to remove it from the box.If you plan to store the board before installation, place it back in the box, close the lid, and store it in a clean, dry, and safe location.If you plan to install the board into a drive immediately, place it on a flat, clean surface.Put on the wrist strap and use a sharp blade to open the anti-static bag.Hold the board by its sides and remove it from the bag.Place the circuit board on top of the anti-static bag.
