DS200CPCAG1 output module
DS200CPCAG1 output module
The GE Contactor Breadboard DS200CPCAG1 has one 12-pin connector and two 2-pin connectors.It also has four terminal strips for connecting up to twelve signal wires.The GE Contactor Breadboard DS200CPCAG1ABB also houses a 24VDC 15A socket power relay.There are moving parts inside the relay, so careful consideration is required when installing the circuit board in the driver.The relay can be easily damaged if it strikes metal structures or other components within the transmission case.The relay is tall and sticks out from the board surface, making it easy to hit.When sliding the motherboard into the drive enclosure, make sure you have a clear view of the motherboard and the inside of the enclosure.Slowly insert the motherboard and align it with the screws on the chassis.Insert the screw into the hole with one hand and turn the screwdriver with the other hand to secure the screw.However, do not tighten the motherboard so tightly that the screws may crack the motherboard and damage it.Use washers if they are provided or used on the defective circuit board.Then, open the screws on the terminal board and insert the wires into the corresponding terminals.Use one hand to insert the wire into the terminal and use the other hand to tighten the terminal screw.Grasp the connector and insert the cable into the corresponding connector.Gently press them into the connector, making sure they are fully seated.
